| Maximum Power |
8.6 kW {12 PS} / 8,000 rpm |
| Maximum Torque |
11.3 Nm {1.2 kgfm} / 6,500 rpm |
| Engine Type |
Air-cooled, 4-stroke Single |
| Cylinder Volume |
144 cc |
| Bore x Step |
58.0 x 54.4 mm |
| Compression Comparison |
9.5:1 |
| Valve System |
SOHC, 2 valves |
| Fuel Supply System |
Carburettor: NCV24 |
| Ignition System |
DC-CDI |
| Start |
Electric & Kick |
| Transmission |
5-speed, return |
| Primary Reduction Ratio |
2.880 (72/25) |
| Final Reduction Ratio |
3.714 (52/14) |
| Clutch |
Wet multi-disc, manual |
| System Final Drive Type |
Chain |
