| Maximum Power |
14.0 kW {19 PS} / 7,600 rpm |
| Maximum Torque |
19.8 Nm {2.0 kgfm} / 6,100 rpm |
| Engine Type |
Air-cooled, 4-stroke Single |
| Cylinder Volume |
233 cc |
| Bore x Step |
67.0 x 66.0 mm |
| Compression Comparison |
9.4:1 |
| Valve System |
SOHC, 2 valves |
| Fuel Supply System |
Fuel injection: ø32 mm x 1 |
| Ignition System |
Digital |
| Start |
Electric |
| Transmission |
6-speed, return |
| Primary Reduction Ratio |
2.871 (89/31) |
| Final Reduction Ratio |
3.071 (43/14) |
| Clutch |
Wet multi-disc, manual |
| System Final Drive Type |
Chain |
