| Maximum Power |
9.6 kW {13 PS} / 7,500 rpm |
| Maximum Torque |
13.2 Nm {1.3 kgfm} / 6,000 rpm |
| Engine Type |
Air-cooled, 4-stroke Single |
| Cylinder Volume |
177 cc |
| Bore x Step |
65.5 x 52.4 mm |
| Compression Comparison |
9.1:1 |
| Valve System |
SOHC, 2 valves |
| Fuel Supply System |
Carburettor: Mikuni VM24 |
| Ignition System |
DC-CDI |
| Start |
Electric |
| Transmission |
5-speed, return |
| Primary Reduction Ratio |
3.667 (77/21) |
| Final Reduction Ratio |
2.333 (35/15) |
| Clutch |
Wet multi-disc, manual |
| System Final Drive Type |
Chain |
