| Ignition system |
TCI |
| Battery |
YTZ7V (ABS Version), NTZ6V (Standard Version) |
| Spark Plug Type |
NGK/CPR8EA-9 |
| Number / Position of Cylinders |
Single Cylinder |
| Engine Capacity |
155cc |
| Bore x Step |
58.0 mm x 58.7 mm |
| Compression Comparison |
11.6 : 1 |
| Maximum Power |
11.3 kW / 8000 rpm |
| Maximum Torque |
13.9Nm / 6500rpm |
| Starter System |
Electric Starter |
| Lubrication System |
Wet |
| Engine Oil Capacity |
Total – 1.00 L; Berkala 0.90 L |
| Fuel System |
FI (Fuel Injection) |
| Clutch Type |
Dry, Centrifugal Automatic |
| Transmission Type |
V-belt Automatic |
| Engine Type |
Liquid cooled 4-stroke, SOHC |
