| Ignition System |
TCI |
| Battery |
GTZ4V/YTZ4V (All New R15 Connected), YTZ6V (All New R15M Connected) |
| Spark Plug Type |
MR8E9 |
| Engine Type |
Liquid Cooled, 4-Stroke, SOHC, 4 Valve, VVA |
| Number / Position of Cylinders |
Single Cylinder |
| Cylinder Contents (CC) |
155.09 cc |
| Bore x Step |
58.0 x 58.7 mm |
| Compression Comparison |
11.6±0.4 : 1 |
| Maximum Power |
14.2 kW / 10000 rpm |
| Maximum Torque |
14.7 Nm / 8500 rpm |
| Starter System |
Electrical Starter |
| Lubrication System |
Wet Sump |
| Engine Oil Capacity |
Total =1.15L ; Periodic = 0.95 L ; Change oil filter = 1 L |
| Fuel System |
Fuel Injection |
| Clutch Type |
Multi Wet Clutch |
| Transmission Type |
Manual |
| Transmission Operating Pattern |
1-N-2-3-4-5-6 |
